PATON ProTIG AC/DC TIG/MMA - 10 -
- "T◦" indicator of the temperature of the most heated parts of the device. If it
glows red, it means that the device is overheated and you need to wait until it cools
down, and then the indicator becomes green again.
- "W" welding process indicator. If it is blue, it means that the welding process
is going on (the button on the torch is pressed) and the setting of all parameters is
not available. Attention! To start the process in the MMA mode after setting the
mode, you have to press the "Enter" button.
- "V" Cooler liquid flow indicator. If it glows red, then the flow switch is not
connected, or there is no coolant flow. Attention! If the indicator is red, then TIG
welding will not be available.
6. The cyclorama of the selected welding mode is displayed. It is different for
each type of welding.
7. Button mode status indicators on 2T, 4T, or PED (pedal mode) torches.
8. Pulse mode indicator: - "P" pulse mode on.
- "N" pulse mode off.
9. Indicator of saving the user program. If "S" is on, it means that the program is
already stored in the memory of the device.
3.1 Designation of parameters of all welding modes
1. "BUTTON MODE" – button mode on the torch, 2Т/4Т/ PED.
2. "PREFLOW" – pre-purge time.
3. "START CURRENT" – start current.
4. "RISE TIME" – current ramp up time.
5. "MAIN CURRENT" – main welding current.
6. "FALL TIME" – current decay time.
7. "FINISH CURRENT" – end current.
8. "POSTFLOW" – post-purge time.
9. "BALANCE" – AC balance.
10. "FREQUENCY" – AC frequency.
11. "PULSE BALANCE" – pulse shape balance.
12. "PULSE FREQUENCY" – pulse frequency.
13. "LOW CURRENT" – lower current (pulse mode).
14. "PULSE TIME" – pulse time (RIV).
15. "PEAK CURRENT" – peak current (RIV).
16. "ANTISTICK" – anti-stick function.
