PATON ProTIG AC/DC TIG/MMA - 24 -
Now you can start welding. After the minimum pressure on the pedal, the arc
will ignite at the start current that you set (START CURRENT). The welding current
will be adjusted according to the pressure of the pedal (the more the pedal is
pressed, the more current). If the pedal is pressed to the lower limit, the maximum
current that you set (MAIN CURRENT) will be set. In short, the pedal allows you to
change the current during welding from "START CURRENT" to "MAIN CURRENT".
9. MAINTENANCE
WARNING! Before opening the machine, switch it off and disconnect the
mains plug. Allow the internal circuits of the machine to discharge (approx. 10 min.)
before proceeding. Place a sign prohibiting switching on when leaving.
To keep the machine in good working condition for many years, several rules
must be observed: Perform safety inspections at specified intervals (see Section
"Safety Instructions").
10. STORAGE REGULATIONS
Preserved and packed source should be kept in storage conditions of State
Standard 15150-69 for 5 years.
Unpacked source should be stored in a dry closed room at air temperature not
lower than +5 °C. There should be no vapors of acids and other active substances on
the premises.
11. TRANSPORTATION
Packed source can be transported by all means ensuring its safety in
compliance with the rules of transportation established for the relevant type of
transport.
12. TECHNICAL DATA
WARNING! If the source is designed for a specific supply voltage, its technical
data can be found on the identification plate on the rear panel. In this case, the mains
plug and mains cable must be selected according to the voltage used.
Nominal mains voltage 50/60Hz, V ~220
3х400
Mains voltage variation limits, V
Efficiency (at rated current), %
