SmartNode SN4170 Overview 17
SmartNode 4170 User Manual 1 • General Information
PRI 0/0 - PRI 0/1 RJ-45 connector providing E1 or T1 PRI interface, meeting
all requirements of ITU-T recommendations for G.703. Use a shielded E1
or T1 interface cable for 120 Ohm balanced connections to connect the
SmartNode with an NT or TE.
Note Refer to Appendix C on page 46 for cabling and
Appendix D on page 50 for pin-outs
Console
Used for service and maintenance, the console port (see figure 2 on
page 16) an RS-232 RJ-45 connector, connects the product to a serial
terminal such as a PC or ASCII Terminal (also called a dumb terminal).
Configuration settings:
• 19200 bps
• 8 bits, no parity
• 1 stop bit
• flow control off
12V DC, 1A
Electricity supply socket. (see figure 2 on page 16)
Reset The reset button has several functions, as described in appendix F,
“Reset Button Functions” on page 55.
Table 2. Rear panel ports (Continued)
Port Description
