Connecting SN4171/2ETH models to your PC 33
SmartNode 4170 User Manual 4 • Initial Configuration
192.168.1.1
Accessing your SmartNode via a Telnet session displays the login screen. Type the factory default login: admin
and leave the password empty. Press the Enter key after the password prompt.
login:admin
password: <Enter>
192.168.1.1>
After you have successfully logged in you are in the operator execution mode, indicated by > as command line
prompt. With the commands enable and configure you enter the configuration mode.
192.168.1.1>enable
192.168.1.1#configure
192.168.1.1(cfg)#
Changing the WAN IP address
Select the context IP mode to configure an IP interface.
192.168.1.1 (cfg) #context ip ROUTER
192.168.1.1 (ctx-ip) [ROUTER} #
Now you can set your IP address and network mask for the interface ETH 0/0 (WAN). Within this example a
network 172.16.1.0/24 address is assumed. The IP address in this example is set to 172.16.1.99 (you should set
the IP address given to you by your network provider).
192.168.1.1(ctx-ip)[Router]#interface WAN
192.168.1.1(if-ip)[WAN]#no ipaddress DHCP
192.168.1.1(if-ip)[WAN]#ipaddress WAN 172.16.1.99/24
2002-10-28T00:09:40 : LOGINFO : Link down on interface WAN.
2002-10-29T00:09:40 : LOGINFO: Link up on interface WAN.
172.16.1.99(if-ip)[WAN]#
Copy this modified configuration to you new start-up configuration. This will store your changes in
non-volatile memory. Upon the next start-up the system will initialize itself using the modified configuration.
Note The modified configuration is applied immediately. It is not necessary to
reboot the device when changing any configuration parameter.
172.16.1.99(if-ip) [WAN]#copy running-config startup-config
172.16.1.99(if-ip) [WAN]
The SmartNode can now be connected to your network.
Connecting the SmartNode to the Network
In general, the SmartNode will connect to the network via the WAN (ETH 0/0) port and PC hosts, IPPBX, IP
phones, etc. on LAN (ETH 0/1) port. The SmartNode 4170 is equipped with Auto-MDX Ethernet ports, so
you can use straight-through or crossover cables for host or hub/switch connections. (See
figure 11 on
page 34).
