ISDN PRI (E1/T1) Port Pin-outs 52
SmartNode 4170 User Manual D • Port pin-outs
ISDN PRI (E1/T1) Port Pin-outs
Note Pins not listed are not used
Table 8. 1000Base-T RJ-45 Socket
Pin Signal
1 TRD0+
2 TRD0-
3 TRD1+
4 TRD1-
5 TRD2+
6 TRD2-
7 TRD3+
8 TRD3-
Table 9. Port 0/0
Pin Signal
1 RX_TIP
2 RX_RING
3 NC
4 TX_TIP
5 TX_RING
6 NC
7 NC
8 NC
