9
About this guide
This guide describes the SmartNode SN4170 hardware, installation and basic configuration. For detailed soft-
ware configuration information refer to the Trinity Command Line Reference Guide and the available Web Wiz-
ard.
Audience
This guide is intended for the following users:
• Operators
• Installers
• Maintenance technicians
Structure
This guide contains the following chapters and appendices:
• Chapter 1 on page 14 provides information about gateway features and capabilities
• Chapter 2 on page 19 contains an overview describing gateway operation and applications
• Chapter 3 on page 22 provides quick start hardware installation procedures
• Chapter 4 on page 27 provides quick-start procedures for configuring the SmartNode gateway
• Chapter 5 on page 36 contains information on contacting Patton technical support for assistance
• Appendix A on page 39 contains compliance and regulatory information for the gateway
• Appendix B on page 42 contains specifications for the gateways
• Appendix C on page 46 provides cable recommendations
• Appendix D on page 50 describes the gateway’s ports and pin-outs
• Appendix E on page 53 lists the factory configuration settings for SmartNode SN4170
• Appendix F on page 55 describes the Reset button functions
• Appendix G on page 58 provides license information that describes acceptable usage of the software pro-
vided with the SmartNode SN4170
For best results, read the contents of this guide before you install the VoIP Gateway.
