PROXIMITY P series reader
PROXIMITY vandal proof reader
NOTE: Only Red & Black (Power) and Blue &Yellow (Data) are required.
PROXIMITY KP series keypad
NOTE: All devices.
If two readers or keypads are required they are both be wired to same terminals.
Chapter 3 Wiring 11
