4.4 TCU Temperature Controller Parameters Default Parameters
UNIT NUMBER
MNEMONIC
PARAMETER
USER SETTING
SP
Temperature Setpoint
Per product setup
sheet
OPOF
Output Power Offset
0
OP
Output Power
100
ProP
Proportional Band
12
Intt
Integral Time
10
dErt
Derivative Time
0
P-2
Proportional Band#2 (secondary)
-
It-2
Integral Time #2 (secondary)
-
dt-2
Derivative Time #2 (secondary)
-
rtio
Remote Setpoint Ratio
-
bIAs
Remote Setpoint Bias
-
AL-1
Alarm 1
10
AL-2
Alarm 2
10
CONFIGURE INPUT
MNEMONIC
PARAMETER
USER SETTING
tYPE
Input Sensor Type
T
SCAL
Temperature Scale Units
°F
dCPt
Temperature Resolution
0
FLtr
Digital Filtering
1
SPAN
Input Slope
1000
SHFt
Input Offset
0
SPLO
Setpoint Lower Limit
0
SPHI
Setpoint Upper Limit
250
SPrP
Ramp Rate
60
InPt
User Input
PLOC
HCur
Heater Current Scaling
50
CONFIGURE OUTPUT
MNEMONIC
PARAMETER
USER SETTING
CYCt
Cycle Time
2
OPAC
Control Action
REV
OPLO
Output Power Lower Limit Range
0
OPHI
Output Power Upper Limit Range
100
OPFL
Sensor Fail Power Preset
0
OPdP
Output Power Dampening
3
CHYS
ON/OFF Control Hysteresis
1
Tcod
Auto-Tune Dampening Code
2
ANAS
Linear Output Assignment
OP
ANLO
Linear Output Scale Value
0
ANHI
Linear Output Scale Value
100
ANdb
Linear Output Deadband
0
