PeakTech 3435 User Manual

4. Safety Symbols
This symbol, adjacent to a terminal, indicates that, under
normal use, hazardous voltages may be present. Do not touch the
measurement probes in live systems.
This symbol, adjacent to another symbol or terminal
indicates the user must refer to the manual for further information.
INPUT MAX
400V
Do never exceed the maximum input voltage of 400V!
Double insulated case (Protection Class II)
CAT III 3
00V
Overvoltage Category III at 300V
5. Technical Data
Transmitter
Output signal 125 kHz
Voltage measurement 12 … 400 V
Input voltage Max. 400 V AC/DC
Frequency range 0 … 60 Hz
Auto Power Off Nach ca. 1 Std.
Working temperature 0 … 40 °C, 80% R.H.
Storage temperature -20 … 60 °C, 80% R.H.
Height above sea level Max. 2000 m
Power supply 9V Block, NEDA 1604, IE6F22
Power consumption Max. 18 mA
Fuse F 0.5A 500V, 6.3 x 32 mm
Dimensions (WxHxD) 69 x 130 x 32mm
Weight Ca. 130g
Receiver
Tracing depth Depends on medium and application
Single pole application ~ 0 … 2 Meter
Double pole application ~ 0 … 0.5 Meter
Non- Contact- Voltage finder ~ 0 … 0.4 Meter
Auto Power Off Ca. 5 min. (Inactive)
Working temperature 0 … 40 °C, 80% R.H.
Storage temperature -20 … 60 °C, 80% R.H.
Height above sea level Max. 2000 m
Power supply 9V Block, NEDA 1604, IE6F22
Power consumption Ca. 23 mA, max. 40mA
Dimensions (WxHxD) 61 x 192 x 37mm
Weight Ca. 180g
