Lubrication
CAUTION
When lubricating the machine and/or replacing the oil, use
Pegasus recommended oil. Using other oils may damage the
machine.
1.使用油Oil
Use the following oil.
Pegasus designated oil: HIGH SPEED SEWING MACHINE OIL
orEquivalents: ESSOTEX SM22 manufactured by Exxon Mobil.
2.給油のしかたTofillthemachinewithoil
1
H
L
1
Remove cap
1
.
Add the oil until the oil level(see oil gauge
2
)lies between (
H
) and
(
L
) lines.
After filling the tank with oil, replace cap
1
.
3.油の規定量
Required amount of oil
2
H
L
H
L
(H) on oil gauge
2
: Upper limit
(L) on oil gauge
2
: Lower limit
The oil level should always lie between (
H
) and (
L
).
4.手差し注油
Manual lubrication
CAUTION
Always turn off the power and unplug the machine when you
apply oil by hand.
3
4
Apply 2 or 3 drops of oil to needle bar
3
and upper looper holder
4
by hand when the machine is used for the first time or has been left
unused for some time.
図 6
図 5
Fig.6
Fig.5
