Pego ECP200 BASE Series - General Programming Level Information; Key Symbols Used in Programming; Setting and Displaying Temperature Set Points

ECP200 BASE 2/4
Page 13
USE AND MAINTENANCE MANUAL
Rev. 01-09
GENERAL
To enhance safety and simplify the operator’s work, the ECP200 BASE system has two
programming levels; the first level (Level 1) is used to configure the frequently-modified
SETPOINT parameters. The second programming level (Level 2) is for general parameter
programming of the various controller work modes.
It is not possible to access the Level 2 programming directly from Level 1: you must exit
the programming mode first.
KEY TO SYMBOLS
For purposes of practicality the following symbols are used:
• (t) the UP key is used to increase values and mute the alarm.
• (u) the DOWN key is used to decrease values and force defrosting.
SETTING AND DISPLAYING THE SET POINTS
1. Press the SET key to display the current SETPOINT (temperature)
2. Hold down the SET key and press the (t) or (u) keys to modify the SETPOINT.
Release the SET key to return to cold room temperature display: the new setting will be
saved automatically.
5.4
CHAP. 5 – Parameter programming
5.5
5.6
