TECHNICAL CHARACTERISTICS
Power supply
Voltage
230 V~  10% 50/60Hz
Max power (only electronics)
~ 7 VA
Rated current (with all loads connected)
16A
Cold room conditions
Working temperature
-5T40°C <90% R.H. non condensing
Storage temperature
-10T70°C <90% R.H. non condensing
General characteristics
Type of sensors that can be connected
NTC 10K 1%
Resolution
0,1 °C
Sensor read precision
± 0,5 °C
Read range
-45 ÷ +99 °C
Output characteristics (voltage free contacts)
Description
Installed relay
Card output characteristics
Note
Compressor
(Relay 30A AC1)
10A 250V~ (AC3) (2HP)
(100000 cycles)
The sum of
contemporary
absorptions of these
outputs
has not to
exceed 16A
Elements
(Relay 30A AC1)
16A 250V~ (AC1)
Fans
(Relay 16A AC1)
2,7A 250V~ (AC3
Room light
(Relay 16A AC1)
16A 250V~ (AC1)
Aux 1
(Relay 5A AC1)
5(3)A 250V~
Aux 2
(Relay 5A AC1)
5(3)A 250V~
Insulation between relay outputs: 1500V
General electrical protection
Differential magnetothermic circuit breaker 16A
Id = 300mA (Id = 30mA, on request)
Disconnecting power 4.5 kA
Dimensional characteristics
Dimensions
18cm x 9.6cm x 26.3cm (HxPxL)
Insulation / mechanical characteristics
Box protection rating
IP65
Box material
self-extinguishing ABS
PTI of insulation materials
Printed circuits 175
Type of insulation
Class II
Type of action and disconnection
Relay contacts 1B (micro disconnection)
Environmental pollution
2, normal situation
Ball pressure test temperature
75°C for the plastic cover and 100°C for the plastic components
that carry electricity.
CHAP. 4 - Technical characteristics
CHAPTER 4: TECHNICAL CHARACTERISTICS
4.1

Pego ECP202 EXPERT + BASE Series Specifications

General

Brand	Pego
Model	ECP202 EXPERT + BASE Series
Category	Control Panel
Language	English
