Pego ECP202 EXPERT + BASE Series User Manual

ECP202 EXPERT + BASE
Page 21
USE AND MAINTENANCE MANUAL
Rev. 01-20
TELENET MONITORING AND SUPERVISION SYSTEM
For TeleNET connections follow the scheme below. Refer to TeleNET user manual for
instrument configuration.
WARNING: During configuration, at entry “Module” to select the entry "Instrument ECP
Base Series / ECP Expert Series rel. 25 or higher".
NET CONFIGURATION WITH MODBUS-RTU PROTOCOL
For RS485 connections with Modbus-RTU protocol follow the scheme below.
Refer to MODBUS-RTU_ECP202EXP user manual (available on Pego Internet web site)
for MODBUS-RTU communication protocol specification.
