Pego ECP202 EXPERT + BASE Series User Manual

ECP202 EXPERT + BASE
Page 4
USE AND MAINTENANCE MANUAL
Rev. 01-20
GENERAL
The electronic controllers of the ECP202 EXPERT + BASE series have been designed to
control static or ventilated cold rooms.
The ECP202 EXPERT + BASE electronic board allows the user to control all the
components on a refrigeration unit such as compressor, evaporator fans, defrosting
elements and cold room light.
The applications are:
- single-phase static or ventilated refrigeration systems up to 2 HP, with off-cycle or
electrical defrosting.
- out of room unit to be connected to power board for compressor, defrosting and fan
start.
- single-phase evaporator control unit with cold solenoid consensus or remote
condensing unit consensus.
The ABS box is easy to install on the wall as the ECP202 EXPERT + BASE has a
minimum footprint and IP65 protection degree.
PRODUCT ID CODES
200202EXBCS Control and management of the compressor,
defrosting heaters, evaporator fans and cold
room light. Two configurable auxiliary relays.
16A differential magnetothermic protection.
1.1
1.2
CHAPTER 1: INTRODUCTION
CHAP. 1 - Introduction

Pego ECP202 EXPERT + BASE Series Specifications

General
