Pego ES3-M User Manual

Page 10
USER MANUAL
ES SERIES HUMIDIFIER ID CODES
ES3-M single-phase covered humidifier with steam output capacity of 3 Kg/h,
on/off work mode with external enabling, proportional mode with inbuilt
humidity switch and 4-20mA humidity sensor, proportional mode
with 0-10 V signal
ES6-M single-phase covered humidifier with steam output capacity of 6 Kg/h,
on/off work mode with external enabling, proportional mode with inbuilt
humidity switch and 4-20mA humidity sensor, proportional mode
with 0-10 V signal.
ES6 three-phase covered humidifier with steam output capacity of 6 Kg/h,
on/off work mode with external enabling, proportional mode with inbuilt
humidity switch and 4-20mA humidity sensor, proportional mode
with 0-10 V signal.
ES12 three-phase covered humidifier with steam output capacity of 12 Kg/h,
on/off work mode with external enabling, proportional mode with inbuilt
humidity switch and 4-20mA humidity sensor, proportional mode
with 0-10 V signal.
ES24 three-phase covered humidifier with steam output capacity of 24 Kg/h,
on/off work mode with external enabling, proportional mode with inbuilt
humidity switch and 4-20mA humidity sensor, proportional mode
with 0-10 V signal.
ES48 three-phase covered humidifier with steam output capacity of 48 Kg/h,
on/off work mode with external enabling, proportional mode with inbuilt
humidity switch and 4-20mA humidity sensor, proportional mode
with 0-10 V signal.
ES SERIES HUMIDIFIERS TECHNICAL DATA
TECHNICAL DATA and
OPERATING CONDITIONS
ES3-M ES6-M ES6 ES12 ES24 ES48
STEAM PRODUCTION (Kg/h)
3 6 6 12 24 48
ELECTRICAL POWER SUPPLY
230V 50-60HZ 400V 3/N 50-60HZ
POWER (KW)
2 3 4,5 9 18 35
ABSORBED CURRENT (A)
9 13,5 6,5 13 25 51
TYPE OF CONTROL
SLIM EASYSTEAM
ELECTRONIC CONTROL POWER
SUPPLY
230V 50-60HZ
STEAM OUTLET DIAMETER (mm)
25 25 25 25 40 40
NUMBER OF CYLINDERS
1 1 1 1 1 2
WEIGHT (EMPTY) (Kg)
10 10 10 12 19 38
WEIGHT OF WORKING UNIT (Kg)
12 13 13 18 37 74
WATER SUPPLY PRESSURE
1-10 bar
WORKING AMBIENT TEMPERATURE
+1 ÷ +40 °C
WORKING AMBIENT HUMIDITY.
< 60 %RH (90 %RH not condensing)
STORAGE TEMPERATURE
-10 ÷ +70 °C
PROTECTION RATING
IP20
1.4
1.5

Pego ES3-M Specifications

General

Brand	Pego
Model	ES3-M
Category	Humidifier
Language	English
