USER MANUAL
LEVEL 2 PROGRAMMING
1. Level 2 programming allows the user to modify a number of advanced humidifier settings.
These parameters should not be modified without guidance from a PEGO assistance centre or a
specialised technician
VAR. MEANING VALUES
DEFAULT
ES3-M
ES6-M
ES-12
ES-6 ES-24 ES-48
S0
Duration time for de-concentration pump drain
0.1 ÷ 12.7 s
2 2 3 5
S1
Working hours
Ten hours
- - - -
S2
De-concentration discharge interval
Interval, in working (steam production) minutes, for de-
concentration discharge
1 ÷ 250 min
15 15 15 15
S3
Delay time on electrodes current-flowing start after a
pump drain
This parameter, if increased, allows in some particular
installation conditions to avoid problem of differential
intervention delay on power supply line affecting speed of
restarting after water draining
1 ÷ 12 s
2 2 2 2
S4
Water discharge following period of non-use
Cylinder emptied completely because machine has been
idle for the set period
1 – 24 h
1 1 1 1
S5
Minimum current differential between one water fill
and the next
0.2 ÷ 10 A
1 0,7 1 1
S6
Pump activation overcurrent percentage
1 ÷ 50 %
25 25 20 15
S7
Pump discharge time overcurrent
0.1 ÷ 5.0 s
0.5 0.5 0.5 0.5
S8
Minimum current differential for water feed during
total or partial cylinder filling
S8=0.0 set the cylinder filling step-by-step
0.0 ÷5.0 A
0.1 0.1 0.3 0.5
S9
Settings:
S9=0 ON-OFF
S9=1 PROPORTIONAL WITH SENSOR 4-20mA
S9=2 PROPORTIONAL WITH INPUT 0-10V
S9=3 PROPORTIONAL WITH SENSOR 4-20mA and
max limit in duct (4-20mA)
S9=4 PROPORTIONAL WITH INPUT 0-10V and
max limit in duct (4-20mA)
0-1-2-3-4
0 0 0 0
CA1
Humidity sensor calibration
(not used on ON/OFF versions)
-20 % ÷ 20 %
0 % 0 % 0 % 0 %
CA2
Humidity duct sensor calibration
-20 % ÷ 20 %
0 % 0 % 0 % 0 %
t1
Time delay humidity duct (in seconds).
This time delay start when there are the condition to
produce steam in the duct ( duct humidity < StC-r0)
(used only with S9=3 and S9=4)
0-240 s
10 s 10 s 10 s 10 s
Ad
Lan address for connection to TeleNET supervision system
or master-slave configuration
0 ÷ 31
0 0 0 0
MS
Master-Slave functioning setting
0= Single 4= Master + 3 slave
1= Slave 5= Master + 4 slave
2= Master + 1 slave 6= Master + 5 slave
3= Master + 2 slave
0-1-2-3-4-5-6 0 0 0 0
rEL
Release software
only read 5 5 5 5
