Page 14
USER MANUAL
IMPORTANT INFORMATION FOR THE INSTALLER
1. The installation, maintenance and use of the equipment must be performed by qualified
personnel capable of executing all the operations required in complete safety.
Read this manual carefully before performing any task and follow all directions
2. Install the unit as close as possible to the point at which you wish to emit steam (i.e. a
position that minimises the length of the steam tube: this should not be more than 5 m long)
3. Install at a height which gives easy access to the control unit used to set the parameters. An
above-ground height of about 1 metre is advised.
4. Install at a height that allows easy access to the humidifier interior for cylinder replacement
purposes.
5. Some humidifier’s parts, during operation, can exceed 60°C temperature. Make sure the
surfaces in contact with them are consistent with those values.
6. Do not install and use the humidifier near to products and objects that can be damaged by
water or produced humidity.
7. Do not fit power supply wiring and signal wiring (probes/sensors and digital inputs) in the
same raceways or ducts.
8. Minimise the length of connector wires so that wiring does not twist into a spiral shape as this
could have negative effects on the electronics.
9. Place a general magneto-thermal cut-off switch upstream from the electronic controller.
10. All conductors used in wiring must be proportionate to support the load that they have to
supply.
11. When it is necessary to make a probe/sensor extension, the wires must have a cross-section of
at least 1 mm
2
.
12. Connect up the water discharge point to a hose with a diameter of at least 40 mm: make sure
the hose does not have any narrow passages and does not at any point exceed the level of the
discharge coupling.
13. Fill with potable water only at a pressure of 1 - 10 bar.
CHAP. 2 INSTALLATION
