ES SERIES SPARE PARTS LIST
Ref. Code Description
1
UMIBA01 ABS support base
2
UMISIFONE1 Water drain siphon (exceeding water or deconcentration drain)
2 + 9
400UMSIF01
400UMSIF02
400UMSIF03
Complete siphon kit + water drain pipes for ES3-M, ES6, ES6-M
Complete siphon kit + water drain pipes for ES12
Complete siphon kit + water drain pipes for ES24 e ES48
3
UMICO25 DN25 lower flange
3A
UMICO25
UMICO40
UMICO40
DN25 steam output flange for ES3-M, ES6, ES6-M, ES12 models
DN40 steam output flange for ES24 e ES48 models
DN40 steam output flange in case fan unit is present
4
400UMCL01
400UMCL02
400UMCL03
400UMCL04
400UMCL05
Electrodes cylinder for ES6
Electrodes cylinder for ES12
Electrodes cylinder for ES24, ES48
Electrodes cylinder for ES3-M
Electrodes cylinder for ES6-M
5
UMIMOLLA1
UMIMOLLA2
UMIMOLLA3
UMIMOLLA4
Cylinder fixing spring for ES6, ES6-M
Cylinder fixing spring for ES12
Cylinder fixing spring for ES24, ES48
Cylinder fixing spring for ES3-M
6
UMITUBO10-2
UMITUBO10-3
Tap water inlet pipe (L=1250mm) for ES3-M, ES6, ES6-M
Tap water inlet pipe (L=1600mm) for ES12, ES24
7
400UMIVALV
400UMIVALV48
230V 50/60 Hz solenoid valve for water filling
for ES3-M, ES6, ES6-M, ES12,
ES24
230V 50/60 Hz solenoid valve for water filling for ES48
8
UMIPOMPA943 230V 50/60 Hz asyncronous drain pump
10
UMIBACK1
UMIBACK2
UMIBACK3
Stainless steel case for ES3-M, ES6, ES6-M
Stainless steel case for ES12
Stainless steel case for ES24
11+13
400SLIMES3M
400SLIMES6M
400SLIMES6
400SLIMES12
400SLIMES24
Control electronic kit 100 Master + Slim display for ES3-M
Control electronic kit 100 Master + Slim display for ES6-M
Control electronic kit 100 Master + Slim display for ES6
Control electronic kit 100 Master + Slim display for ES12
Control electronic kit 100 Master + Slim display for ES24
12
CON10161AP01
CON10241AL20
Contactor for electrodes power supply for
ES3-M, ES6, ES6-M, ES12
Contactor for electrodes power supply for ES24, ES48
14
UMIOR1 O-Ring diameter 88,49 X 3,53 SILICON 60Sh.
15
UMICURVA90° 24mm joint elbow 90°
Request spare parts from your dealer.
