Page 51
USER MANUAL
OEM SERIES SPARE PARTS LIST
Ref. Code Descriprion
1
UMICO25 DN25 lower flange
1A
UMICO25
UMICO40
UMICO40
DN25 steam output flange for ES3-M-OEM, ES6-OEM, ES6-M-OEM, ES12-OEM models
DN40 steam output flange for ES24-OEM model
DN40 steam output flange in case fan unit is present
2
400UMCL01
400UMCL02
400UMCL03
400UMCL04
400UMCL05
Electrodes cylinder for ES6-OEM
Electrodes cylinder for ES12-OEM
Electrodes cylinder for ES24-OEM
Electrodes cylinder for ES3-M-OEM
Electrodes cylinder for ES6-M-OEM
3
UMIMOLLA1
UMIMOLLA2
UMIMOLLA3
UMIMOLLA4
Cylinder fixing spring for ES6-OEM, ES6-M-OEM
Cylinder fixing spring for ES12-OEM
Cylinder fixing spring for ES24-OEM
Cylinder fixing spring for ES3-M-OEM
4
UMISIFONE1 Water drain siphon (exceeding water or deconcentration drain)
4+5
400UMSIF04 (*)
400UMSIF05 (*)
400UMSIF06
(*)
Complete siphon kit + water drain pipes for ES3-M-OEM, ES6-OEM, ES6-M-OEM (new version)
Complete siphon kit + water drain pipes for
ES12-OEM (new version)
Complete siphon kit + water drain pipes for ES24-OEM (new version)
4+5
400UMSIF04V (*)
400UMSIF05V
(*)
400UMSIF06V
(*)
Complete siphon kit + water drain pipes for ES3-M-OEM, ES6-OEM, ES6-M-OEM (old version)
Complete siphon kit + water drain pipes for ES12-OEM (old version)
Complete siphon kit + water drain pipes for ES24-OEM (old version)
6
UMITUBO10-2 Tap water inlet pipe (L=1250mm)
7
UMILAMCUST aisi 316 stainless steel sheet panel bracket
8
UMIPOMPA943
230V 50/60 Hz asyncronous drain pump
9
UMIVALV1
230V 50/60 Hz solenoid valve for water filling
10
-
Solenoid fixing screws
11
-
Pump fixing screws
12
UMIMAN12
DN25 hose for water drain
13
UMIGOM12
½ gas elbow
14
UMIPORTGOM12
½ gas hose bracket
15
UMIOR1
O-Ring diameter 88,49 X 3,53 SILICON 60Sh.
16
UMICURVA90°
24mm joint elbow 90°
(*): New water drain part differs from old one on the stainless steel drain components instead
plastic. On the new version 12, 13 and 14 reference are not present.
Request spare parts from your dealer.
