Peimar Mirus Series User Manual

76
EN
4.4.4 Mount the inverter
Carefully mount the inverter to the rear panel as shown in Figure 4.12, Figure
4.13, Figure 4.14. Make sure that the rear part of the equipment is closely
mounted to the rear panel. Use the two specic screws to lock the inverter to
the rear panel.
Figure 4.12 Mount PSI-J1000-TL / PSI-J1500-TL
Figure 4.13 Mount PSI-J2000-TL / PSI-J2500-TL / PSI-J3000-TL
Figure 4.14 Mount PSI-J3000-TLM / PSI-J4000-TLM / PSI-J5000-TLM / PSI-J6000-TLM
