pellenc EXCELION 2000 - Angle Transmission Lubrication; Spare Parts and Consumables References

32
53_12_038C
53_12_053B
1 2 3 4
DOC_53_17_017A
■ MAINTENANCE
 ENONEEEENE
Safety elements:
 NENIIONIION
Loosen the screw located on the angle transmission using the adjusting wrench.
Open the tube of PELLENC grease
Apply 4g of PELLENC grease, once a month or every 100 hours.
Grease the threads of the shaft of the angle to facilitate the release of the cutting head nuts.
Tube of lubrication grease = 35749
Standard housing, ref. 107533
Grinding chamber, ref. 111600
Chisel-tooth saw housing, ref. 111500
CityCut housing, ref. 118267
For specic lubrication of the angle gear of the CITY CUT cutting
head, refer to the "Greasing" section on p. 31.
Standard angular gearbox Universal angular gearbox
