Operation Flow Chart
1: Set user interface to desired temperature.
ROOM:68 SET: 72
START UP 11:59
2: Exhaust blower turns on.
3: Igniter turns on.
4: Vacuum switch closes.
5: Feed motor will turn on after the 1 min igniter preheat
sequence expires. Initial feed will be for 60 seconds
and stop.
6: Pellets ignite in the repot.
