System 450™ Series Modular Control Systems with Standard Control Modules Technical Bulletin
57
Table 15: System 450 Compatible TE-6000 Series 1,000 Ohms Nickel Temperature Sensors and
Accessories Ordering Information
Product Code
Number
Product Description
TE-6000-x TE6000 Series 1,000 ohms at 21C (70F) nickel temperature sensors (only). Only the TE-6000-6
sensor can be used for the entire HIC and HIF temperature range. Different sensing element
packages are available for various applications. For a complete list of compatible 1,000 ohms nickel
sensors, including sensor descriptions, technical specifications, and mounting accessories, refer to the
TE-6000 Series Temperature Sensing Elements Product Bulletin (LIT-216288). (System 450 Sensor
Types HIC and HIF.)
Table 16: System 450 Compatible TE-6300 Series 1,000 Ohms Nickel Temperature Sensors and
Accessories Ordering Information
Product Code
Number
Product Description
TE-631x-x TE6300 Series 1,000 ohms nickel averaging and 1,000 ohms thin-film nickel temperature sensors
(only). For a complete list of compatible 1,000 ohms nickel averaging and thin-film nickel sensors,
including sensor descriptions, technical specifications, and accessories, refer to the TE-6300 Series
Temperature Sensors Product Bulletin (LIT-216320). (System 450 Sensor Types HIC and HIF.)
Table 17: System 450 Compatible TE-68NT-0N00S 1,000 Ohms Nickel Temperature Sensor Ordering
Information
Product Code
Number
Product Description
TE-68NT-0N00S TE6800 Series 1,000 ohms at 21C (70F) nickel temperature sensor for wall-mount applications. For
more information, including sensor description, technical specifications, and mounting accessories,
refer to the TE-6800 Series Temperature Sensors Product Bulletin (LIT-12011542). (System 450
Sensor Types HIC and HIF.)
Table 18: System 450 Compatible HE67S3 Type Humidity Sensors with Integral A99B Temperature Sensor
Ordering Information
1
Product Code
Number
Product Description
HE-67S3-0N0BT Wall Mount Humidity Sensor with A99B Type Temperature Sensor: 10 to 90% RH;
-40 to 121C (-40 to 250F)
HE-67S3-0N00P Duct Mount Humidity Sensor with A99B Type Temperature Sensor: 10 to 90% RH;
-40 to 121C (-40 to 250F)
1. The HE-67S3 sensors require 24 VAC input and must use the 0–5 VDC output. Refer to the TrueRH Series HE-67xx
Humidity Element with Temperature Sensors Product Bulletin (LIT-216245) on the Johnson Controls QuickLIT website for
more information, including technical specifications and mounting accessories.
Table 19: System 450 Compatible HE6800 Series Humidity Transmitters with Temperature Sensor Ordering
Information
1
Product Code
Number
Product Description
HE-68N2-0N00WS Wall Mount Humidity Transmitter with Nickel Temperature Sensor: 10 to 90 ±2% RH;
0 to 55C (32 to 131F)
HE-68N3-0N00WS Wall Mount Humidity Transmitter with Nickel Temperature Sensor: 10 to 90 ±2% RH;
0 to 55C (32 to 131F)
1. The HE-6800 transmitters require 24 VAC input and must use the 0–5 VDC output. Refer to the HE-6800 Series Humidity
Transmitters with Temperature Sensor Product Bulletin (LIT-12011625) on the Johnson Controls QuickLIT website for more
information, including technical specifications and mounting accessories.
