System 450™ Series Modular Control Systems with Standard Control Modules Technical Bulletin
58
Table 20: System 450 Compatible Low Pressure Differential Transducer Ordering Information
1,2
1. Refer to the Setra Systems Model DPT265 Very Low Differential Pressure Transducer Catalog Page on the Johnson
Controls QuickLIT website.
2. The DPT265 sensors require 24 VAC input and must use the 0–5 VDC output. Refer to the Setra Systems Model DPT265
Very Low Differential Pressure Transducer Catalog Page on the Johnson Controls QuickLIT website.
Product Code
Number
Product Description
DPT2650-0R5D-AB Low Pressure Differential Transducer: 0 to 0.5 in. W.C. (System 450 Sensor Type: P 0.5)
DPT2650-2R5D-AB Low Pressure Differential Transducer: 0 to 2.5 in. W.C. (System 450 Sensor Type: P 2.5)
DPT2650-005D-AB Low Pressure Differential Transducer: 0 to 5.0 in. W.C. (System 450 Sensor Type: P 5)
DPT2650-10D-AB Low Pressure Differential Transducer: 0 to 10 in. W.C. (System 450 Sensor Type: P 10)
Table 21: System 450 Compatible P499 Series Transducers with 1/4 in. SAE 45 Flare Internal Thread with
Depressor (Style 47) Ordering Information
1
1. The P499 sensors must be powered with the +5 VDC and C terminals and the output is 0.5 to 4.5 VDC. Refer to the P499
Series Electronic Pressure Transducers Product/Technical Bulletin (LIT-12011190) on the Johnson Controls QuickLIT
website.
Product Code
Number
Product Description Availability
P499RCP-401C -1 to 8 bar; order WHA-PKD3 type wire harness separately. Only available in
Europe
P499RCP-402C -1 to 15 bar; order WH A-PKD3 type wire harness separately. Only available in
Europe
P499RCP-404C 0 to 30 bar; order WHA-PKD3 type wire harness separately. Only available in
Europe
P499RCP-405C 0 to 50 bar; order WHA-PKD3 type wire harness separately. Only available in
Europe
P499RCPS100C -10 to 100 psis (sealed for wet and freeze/thaw applications); order WHA-PKD3
type wire harness separately.
Only available in
North America
P499RCPS100K -10 to 100 psis (sealed for wet and freeze/thaw applications); WHA-PKD3-200C
wire harness included.
Only available in
North America
P499RCPS102C 0 to 200 psis (sealed for wet and freeze/thaw applications); order WHA-PKD3
type wire harness separately.
Only available in
North America
P499RCPS102K 0 to 200 psis (sealed for wet and freeze/thaw applications); WHA-PKD3-200C
wire harness included.
Only available in
North America
P499RCP-101C 0 to 100 psig; order WHA-PKD3 type wire harness separately. Only available in
North America
P499RCP-101K 0 to 100 psig; WHA-PKD3-200C wire harness included. Only available in
North America
P499RCP-105C 0 to 500 psig; order WHA-PKD3 type wire harness separately. Only available in
North America
P499RCP-105K 0 to 500 psig; WHA-PKD3-200C wire harness included. Only available in
North America
P499RCP-107C 0 to 750 psig; order WHA-PKD3 type wire harness separately. Only available in
North America
P499RCP-107K 0 to 750 psig; WHA-PKD3-200C wire harness included. Only available in
North America
