System 450™ Series Modular Control Systems with Standard Control Modules Technical Bulletin
59
Table 22: System 450 Compatible P499 Series Transducers with 1/8 in. 27 NPT External Thread (Style 49)
Ordering Information
1
Product Code
Number
Product Description
P499RAPS100C -10 to 100 psis (sealed for wet and freeze/thaw applications); order a WHA-PKD3 type wire harness
separately.
P499RAPS100K -10 to 100 psis (sealed for wet and freeze/thaw applications); WHA-PKD3-200C wire harness
included.
P499RAPS102C 0 to 200 psis (sealed for wet and freeze/thaw applications); order WHA-PKD3 type wire harness
separately.
P499RAPS102K 0 to 200 psis (sealed for wet and freeze/thaw applications); WHA-PKD3-200C wire harness included.
P499RAP-101C 0 to 100 psig; order a WHA-PKD3 type wire harness separately.
P499RAP-101K 0 to 100 psig; WHA-PKD3-200C wire harness included.
P499RAP-102C 0 to 200 psig; order a WHA-PKD3 type wire harness separately.
P499RAP-105C 0 to 500 psig; order WHA-PKD3 type wire harness separately.
P499RAP-105K 0 to 500 psig; WHA-PKD3-200C wire harness included.
P499RAP-107C 0 to 750 psig; order WHA-PKD3 type wire harness separately.
P499RAP-107K 0 to 750 psig; WHA-PKD3-200C wire harness included.
1. The P499 sensors must be powered with the +5 VDC and C terminals and the output is 0.5 to 4.5 VDC. Refer to the P499
Series Electronic Pressure Transducers Product/Technical Bulletin (LIT-12011190) on the Johnson Controls QuickLIT
website.
Table 23: WHA-PKD3 Wire Harnesses Ordering Information
1
Product Code
Number
Product Description
WHA-PKD3-200C Plug and 3-Wire Harness for P499 Electronic Pressure Transducers: 2.0 m (6.5 ft) cable
WHA-PKD3-400C Plug and 3-Wire Harness for P499 Electronic Pressure Transducers: 4.0 m (13 ft) cable
WHA-PKD3-600C Plug and 3-Wire Harness for P499 Electronic Pressure Transducers: 6.0 m (19.6 ft) cable
1. Refer to the P499 Series Electronic Pressure Transducers Product/Technical Bulletin (LIT-12011190) on the Johnson
Controls QuickLIT website.
Table 24: System 450 Compatible P598 Series Transducers with 1/4 in. SAE 45 Flare Internal Thread with
Depressor (Style 47) Ordering Information
1
(Part 1 of 2)
Product Code
Number
Product Description Availability
P598RCPSN401C
-1 to 8 bar; order WHA-PKD3 type wire harness separately. Only available in
Europe
P598RCPSN402C
-1 to 15 bar; order WH A-PKD3 type wire harness separately. Only available in
Europe
P598RCPSN404C
0 to 30 bar; order WHA-PKD3 type wire harness separately. Only available in
Europe
P598RCPSN405C
0 to 50 bar; order WHA-PKD3 type wire harness separately. Only available in
Europe
