TYPICAL RESIDENTIAL SYSTEM PLUMBING
Soft Water
Hard Water
Outside
Faucet
Outside
Faucet
Bath TubLavatoryToilet Kitchen
Laundry Tubs
Pump
or
Meter
Hot Water
Outlet
Water
Heater
Brine Tank Overow Drain (Optional)
Floor Drain
Drain Line
Bypass
Softener
Grounding
Strap
Figure 1 Softened Water Flow
