,Q&DQDGDWKLVSRROKHDWHUFDQRQO\EHLQVWDOOHGRXWGRRUVRULQDQHQFORVXUHWKDWLVQRWQRUPDOO\RFFXSLHGDQGKDVQR
GLUHFWRSHQLQJVLQWRRFFXSLHGDUHDV
WARNING
Risk of asphyxiation if exhaust is not correctly vented. Follow venting instructions exactly when installing heater. Do not
use a draft hood with this heater, as the exhaust is under pressure from the burner blower and a draft hood will allow exhaust
fumes to blow into the room housing the heater. Exhaust venting to the outdoors is required for all outdoor shelter installations.
WARNING
Risk of explosion if a unit burning propane gas is installed in a pit or other low spot. Propane is heavier than air. Do
not install the heater using propane in pits or other locations where gas might collect. Consult your local building code officials
to determine installation requirements and specific installation restrictions of the heater relative to propane storage tanks and
filling equipment. Installation must meet the requirements for the Standard for the Storage and Handling of Liquefied Petroleum
Gases, CAN/CSA B149.2 (latest edition) or ANSI/NFPA 58 (latest edition). Consult local codes and fire protection authorities
about specific installation restrictions.
7KHKHDWHULVGHVLJQFHUWL¿HGE\&6$,QWHUQDWLRQDOIRULQVWDOODWLRQRQFRPEXVWLEOHÀRRULQJLQDOFRYHVEDVHPHQWVLQ
FORVHWRUXWLOLW\URRPVLQWKH86
GARAGE OR UTILITY ROOM INSTALLATION
,Q&DQDGDWKHKHDWHUPXVWEHLQVWDOOHGLQDURRPWKDWLVQRWQRUPDOO\RFFXSLHGDQGKDVQRRSHQLQJV
GLUHFWO\WRRFFXSLHGDUHDV
WARNING
Risk of fire and explosion if installed at floor level in an automotive garage or near gasoline or flammable liquid storage.
Gasoline fumes are heavier than air and will settle to floor level in closed spaces. Gasoline fumes and spilled gasoline or other
volatile liquids (such as some paints and varnishes) will travel across the floor and can be ignited by a gas appliance.
,QDQ\XWLOLW\URRPRUUHVLGHQWLDOJDUDJHLQVWDOODWLRQLQVWDOOWKHKHDWHUZLWKWKHEDVHDWOHDVWLQFKHV0DERYHWKH
ÀRRUVHH
)LJXUH,QDJDUDJHLQVWDOODUDLORUZDOOWRSURWHFWWKHKHDWHUIURPSK\VLFDOGDPDJHE\DPRYLQJYHKLFOH
3URYLGHDQDGHTXDWHYHQWLODWLRQDLUVXSSO\6HH7DEOHSDJH&KRRVHDORFDWLRQWKDWZLOODYRLGFRQWDPLQDWLRQ
E\FKHPLFDOIXPHV
CAUTION
A Propane (LPG) fired heater must not be installed in a garage in
Massachusetts, by order of the Massachusetts State Fire Marshal. For
more information, call the Massachusetts State Fire Marshal’s office.
127,&(&RPEXVWLRQDLUFRQWDPLQDWHGE\FRUURVLYHFKHPLFDOIXPHV
FDQGDPDJHWKHKHDWHUDQGZLOOYRLGWKHZDUUDQW\
6HH
7DEOHSDJH
Section 3. Installation Instructions
OUTDOOR SHELTER INSTALLATION
Leave 6 in. (15 cm)
of clear space between
heater and combustible
surface.
Leave 3 ft. (1 m)
or more of clearance
above heater
RAISE AT LEAST
18 in. (46 cm) above floor
to avoid flammable vapors
18 in.
Figure 19.

Pentair MASTERTEMP 125 Specifications

General

BTU Output	125, 000 BTU/hr
Fuel Type	Natural Gas or Propane
Ignition System	Electronic
Minimum Flow Rate	20 GPM
Maximum Working Pressure	50 PSI
Efficiency	82%
Water Connections	1.5 inch
Certifications	ANSI Z21.56
Voltage	120V
