PRE-INSTALLATION
T
Quick Connect Nut
Red Arrow
Water Filter Head
Water Softener
Alternative
INLET
OUTLET
Figure 2
Thebypassvalvecomespre-assembledandreadytoinstallwiththeo-rings,splitrings,andquickconnectnuts.Pushthe
bypassvalveintotheheadoftheNaturSoft®WaterSoftenerAlternativewiththeunthreadedendsorientedtowardthetanksand
hand-tighten the quick connect nuts.

The bypass valve(s) included with this system are designed for multiple water systems. This may result in the arrows on the
bypass valve(s) pointing differently than shown. If the arrows on your bypass valve(s) do not match the diagram, remove the

Notice
 turn.
Head may not move at all or less than  turn.
WATER SOFTENER ALTERNATIVE WITH NATURSOFT® SALT-FREE TECHNOLOGY•5
