SEDIMENT FILTER INSTALLATION
Sediment Filter Cover
Sediment Filter
O-Ring x2
Stand Pipe
Blue Filter Housing
Part 1
1. Unscrewthecoverfromthebluelterhousing.
2.Removetheplasticcoveringfromthesedimentlter.
3.Placethesedimentlterontothestandpipeinthebluelterhousingandsetaside.
Part 2
1. Shutoffthewater.
2.Attachtheltercovertothemountingbracketusingthesuppliedboltheadscrewsandwashers.Makesuretoproperly 
 orientatetheINandOUTtomatchyourowpattern.
3.Attachthemountingbrackettothewallusingthesuppliedphillipsheadscrews.
4.Handtightenthebluelterhousingandthen,usingthesuppliedlterwrench,lightlysnugthehousingmakingsurenotto
 over-tighten(counterclockwise).
5.Determinethesizeofyourinletwatersupplyline.

typically installed in the "pre" position (as shown above) for well-water applications. For city water applications, the sediment

