COMPLETE THE INSTALLATION
1. Check for leaks.
2.Peelofftheprotectiveplasticwrapfromthestainlesssteeltankjacket(s).
3.AddthePentairlogosticker(s)inthedesiredlocationonthetank.
4.Waxstainlesssteeltankjacket(s)withwaxprovided(oranyothernon-abrasiveautowax)aminimumof1-2timesperyearor
as needed based on the installed environment.

CleaningandrestoringtheplumbingsystemisamajorbenetoftheNS3-P/NS6-PNaturSoft®system.Inordertominimize
the time required to complete the decaling process, we strongly recommend cleaning your hot water heater 3 weeks after
installation of your water softener alternative system.
• Turnofftheheatsource,attachahosetothedrainvalveatthebottomofthetankandushtheheaterbyopeningthe
drainvalve.Afterthewaterheateriscompletelylledwithwater,turntheheatsourcebackon.
Figure A
In Service
Figure B
In Bypass
BYPASS VALVE OPERATIONS
FigureAshowsthesystem"inservice"which
allowswatertoowinandoutofthetank.Inthis
position the system would be considered ON.
FigureBshowsthesystem"inbypass"whichwill
direct water straight to the home without going
in and out of the tank. In this position the system
wouldbeconsideredOFF.
WATER SOFTENER ALTERNATIVE WITH NATURSOFT® SALT-FREE TECHNOLOGY • 9
