SPACOMMAND
®
Spa-Side Remote Installation and User’s Guide
Technical Support
Phone: (800) 831-7133 - Fax: (800) 284-4151
visit www.pentairpool.com and www.staritepool.com:
P/N 521198 Rev. B 11/12
CONTENTS
IMPORTANT SAFETY INSTRUCTIONS ............................................................... i
SpaCommand Spa-Side Remote Overview ............................................... 1
Upgrading iS10 Remote .................................................................... 1
Operating the SpaCommand Spa-Side Remote ......................................... 1
SpaCommand Spa-Side Remote Buttons .................................................. 2
EasyTouch and IntelliTouch button assignments ............................... 3
Compool button assignments ........................................................... 3
SpaCommand Spa-Side Remote Kit Contents .......................................... 4
SPACOMMAND SPA-SIDE REMOTE INSTALLATION .............................. 5
Recess Mount Installation (with Mud-Box) ........................................ 5
Spa-Side Remote Mounting Space Dimensions ............................... 5
RECESS MOUNT INSTALLATION (without MUD-BOX) ............................. 6
SURFACE MOUNT INSTALLATION (without MUD-BOX) ........................... 8
REPLACING EXISTING SPACOMMAND REMOTE .................................. 10
UPGRADE EXISTING iS10 REMOTE ...................................................... 11
WIRING THE SPACOMMAND REMOTE TO THE LOAD CENTER ............ 15
Adding Multiple SpaCommand Spa-Side Remotes (IntelliTouch) ............... 17
Setting up SpaCommand Spa-Side Remote (IntelliTouch) ......................... 18
Setting up SpaCommand Spa-Side Remote (EasyTouch).......................... 19
Compool SS8 Remote Upgrade Installation ............................................... 20
