Pentair SPACOMMAND CP3800 Series User Manual

SPACOMMAND
®
Spa-Side Remote Installation and User’s Guide
19
To assign SpaCommand remote buttons (1-4) and (5-8):
Press MENU > SETTINGS > 10 Butn Spa Sd > Press
the Up/Down buttons and select the “Top” or Bottom”
row to assign circuits. Press the Right button to select
the Top button “1” of the remote. Five top row and lower
buttons can be assigned circuits (1/5, 2/5, 3/5, 4/5, 5/5).
Press the Right button to move to the circuit setting.
Press the Up/Down buttons to configure the first button
on the remote, scroll through the circuit names to assign to the first button on the remote.
The default circuit selections are: None, Spa, Pool, Aux 1-7 (EasyTouch 8), Feature 1-8,
Solar (if selected in “Heat” menu), Heat Boost, Heat Enable, Pump Incrs, Pump
Decrs. “Aux Extra” is displayed only available if the Solar output (J17) plug on the
EasyTouch control system circuit board is not being used for solar equipment. Use the
Solar button to switch the extra circuit on and off. Selecting “None” does not assign a
circuit. Note: The “Heat Boost” feature will switch on the heater for seven minutes to
increase the spa water temperature. Each time the spa Heat Boost button is pressed, the
temperature will increase about 1° F. The temperature will not go beyond the 104° F limit.
Press the Right button to assign the next circuit (2/5). When finished, press the Menu
button to save the settings and to return to the Settings menu options. Press the button
twice to return to the main screen.
SETTING UP REMOTE TO EASYTOUCH
®
CONTROL SYSTEM
From the EasyTouch control panel menu, you can specify any SpaCommand
®
Spa-Side
Remote button to control different functions by assigning each button to a specific circuit.
The spa-side remote has 10 assignable circuit buttons; five button on the top row and five
buttons on the bottom row. Note: The EasyTouch system can support two SpaCommand
spa-side remotes, however, the two remotes will mirror each other in functionality. For
more information refer to the EasyTouch Control Systems User’s Guide (P/N 521044).
Setup SpaCommand remote buttons to increase/decrease pump speed/flow
From this menu setting you can specify the IntelliFlo
®
VF, VS, VSF+SVRS Pump speed/
flow (RPM/GPM) in step increments using the “Pump Incrs” or “Pump Decrs” circuit. The
SpaCommand Up/Down buttons can be are assigned to the “Pump Incrs” and “Pump
Decrs” circuits. Each press of the Up/Down button will increase and decrease pump
speed or flow rate in specific speed increments, as specified in the “10B Pump Cntrl”
EasyTouch menu setting. Speed increments are set from 10-250 RPM (1-10 GPM).
To assign a pump step speed or flow rate:
Press MENU > SETTINGS > 10B Pump Cntrl >. Press
the Up/Down button to select the “Pump Number” (Spa
Side Pump #1) as specified in the IntelliFlo menu. Press
the Right button to select the pump “Step” speed (RMP).
Press the Up/Down buttons to adjust the “Step” pump
speed. Press the Right button to select the pump “Size”
(Flow Rate GPM). Press the Up/Down buttons to adjust the GPM flow rate (IntelliFlo VS
and VSF (10-250 RPM - (1-10 GPM VSF only), IntelliFlo VF pump (1-10 GPM). Press the
Menu button to save settings and to return to the Settings menu options. Press the button
twice to return to the main screen.
Assign 10 BtnSS
Row : Top
Circuit : 1/5
[Spa ]
Spa Side Pump #
IFlo Control
Step GPM:050
Size GPM:1
