17
INTELLIFLO3™ VSF / INTELLIPRO3™ VSF Variable Speed and Flow Pump Installation and Maintenance Guide
STRAINER POT BOLT INSERTS (6X or 8X)
STRAINER POT BOLTS (6X or 8X)
WIRING COVER
DRIVE COVER
DRIVE COVER SCREWS (4X)
DRIVE
DRIVE TO MOTOR SCREWS(4X)
MOTOR SHROUD (HALF)
DIFFUSER O-RING
DIFFUSER
IMPELLER
SEALPLATE
SEALPLATE O-RING
SHAFT SEAL
DIFFUSER SCREWS
MOTOR BOLTS (4X)
MOTOR
SHROUD SCREWS (4X)
DRIVE CONNECTOR GASKET
FOOT
FOOT SCREW
STRAINER POT
MOTOR SHROUD (HALF)
Pump Disassembly/Reassembly Diagram
