INTELLIFLOXF
®
and INTELLIPROXF
®
VSF Variable Speed and Flow Pump Installation and User’s Guide
0
10
20
30
40
50
60
70
80
90
100
020406080100 120 140160 180200 220
Total Dynamic Head in Ft of H2O
Volumetric Flow Rate in GPM
S
S
p
p
e
e
e
e
d
d
4
4
@3110 rpm
S
S
p
p
e
e
e
e
d
d
1
1
@750 rpm
S
S
p
p
e
e
e
e
d
d
2
2
@1500 rpm
S
S
p
p
e
e
e
e
d
d
3
3
@2350 rpm
M
M
a
a
x
x
.
.
S
S
p
p
e
e
e
e
d
d
@3450 rpm
OPERATING RANGE FOR
FLOW CONTROL
TECHNICAL DATA
Pump Dimensions
Pump Performance Curves
232
9.1
288
11.4
633
24.9
328
12.9
358
14.1
298
11.7
168
6.6
263
10.4
258
10.2
166
6.5
276
10.9
Electrical Specifications
Circuit Protection: Two-pole 20 AMP device at the Electrical Panel.
Input: 230 VAC, 50/60 Hz, 3200 Watts Maximum, 1 phase
WEF 5.6 THP 3.95
