[Charging the battery]
• The battery BP02 is not charged at our factory shipment. It must be changed before use.
• For BP02 charge, use the special BC03 charger.
[Connection of code]
Å Insert the output plug of the power supply code in Jack of the AC adaptor.
Ç Insert the output plug of the AC adaptor in Jack of the charger.
É Insert the power supply plug of the power supply code in the outlet of AC power supply.
[Installation of battery]
Å Draw the battery to the lock lever side and put it on the battery pocket.
The battery is firmly installed on the battery pocket.
Ç Press down the battery and then slide it to the opposite direction of the lock lever.
É The lock lever goes up, and the battery is fixed.
Ñ Under such a condition, if “Connection of the code” is done, the charge with the battery
is begun.
[Detaching the battery]
Å Press the lock lever and slide the battery to the lock lever direction.
Ç Detach the battery packing from the battery pocket.
12
