Removing CF card
1) Unlock the CF card slot cover by pressing ‘CF OPEN’ button, then, open the cover.
2) Press the Inject button so the CF card pops out.
3) After the CF card is removed, close the Slot cover completely.
1.7 Connecting USB cable
• Be sure to turn the instrument’s power off before connecting or
disconnecting the USB Cable.
1) Open the USB connector cover
2) Insert the USB connector into the USB port in right direction.
3) After the USB is disconnected, close the USB connector cover completely.
• Do not open/close the USB connector cover or connect/disconnect the USB cable outdoors.
16
Be sure the direction of USB
mini B connector is same as
that of the USB port.
To Next Page
