1.5 Inserting / removing SD card
• Be sure to turn the instrument’s power off before inserting or removing the SD card.
Inserting SD card
1) Open the Slot cover
2) Insert the SD card into the slot. (The side with terminal should face the instrument and
the cut-off corner should be up).
3) Insert the SD card to the end. Be sure not to press the card too hard.
After the SD card is inserted, close the Slot cover completely.
Removing SD card
1) Open the Slot cover
2) Lightly press the SD card so the card pops out.
3) After the SD card is removed, close the Slot cover completely.
• Do not open/close the Slot cover or insert/remove the SD card outdoors.
14
