6 Peplink Balance Overview
6.1 Peplink Balance One
6.1.1 Front Panel Appearance
.
6.1.2 LED Indicators
The statuses indicated by the front panel LEDs are as follows:
Power and Status Indicators
Wi-Fi
OFF – Wi-Fi is off
Green – Ready
Status
OFF – Upgrading firmware
Red – Booting up or busy
Blinking red – Boot up error
Green – Ready
LAN and WAN Ports
Green LED
ON – 10 / 100 / 1000 Mbps
Orange LED
Blinking – Data is transferring
OFF – No data is being transferred or port is not connected
Port Type
Auto MDI/MDI-X ports
USB Port
USB Ports
For future functionality
Status LED
USB Port
LAN Ports
WAN Ports
Reset Button
Wi-Fi LED
