6.6 Peplink Balance 210
6.6.1 Front Panel Appearance
6.6.2 LED Indicators
The statuses indicated by the front panel LEDs are as follows:
Power and Status Indicators
Status
OFF – Upgrading firmware
Red – Booting up or busy
Blinking red – Boot up error
Green – Ready
LAN and WAN Ports
Green LED
ON – 10 / 100 / 1000 Mbps
Orange LED
Blinking – Data is transferring
OFF – No data is being transferred or port is not connected
Port Type
Auto MDI/MDI-X ports
USB Port
USB Ports
For connecting a 4G/3G USB modem
WAN Ports
LAN Ports
Status
LED
Reset
Button
USB
