28.8 BGP

Shows status of BGP

28.9 SpeedFusion Status

Current SpeedFusion

status information is located at Status>SpeedFusion

Details about SpeedFusion

connection peers appears as below:

Click on the corresponding peer name to explore the WAN connection(s) status and subnet

information of each VPN peer.
