peplink Pepwave MAX BR1 MK2

To Next Page

To Previous Page

Cellular Indicators

Cellular

OFF

Disabled or no SIM card inserted

Blinking

Connecting to network(s) in Standby Mode

Green

Connected to network(s) in Priority 1 (Active)

LAN and WAN Indicators

Green

Powered-on device connected to Ethernet port

OFF

No device connected to Ethernet port
