Quick Start Functions
Reset Switch
With a paperclip, press and hold the reset button for at least 10+ seconds, until all the lights light
up.
(If you press and hold the reset button for only 5-10 seconds, instead of a factory reset, the
admin user password will be reset to ‘admin’ and access will be reset to HTTP)
Connect Ethernet
Connect an RJ45 cable from an Internet-enabled router to any RJ45 port on the Peplink SD
Switch.
Connect an RJ45 cable from any client device to port 1-24 of the Peplink SD Switch.
Connect SFP+
Remove the protective plastic cover from the SFP+ port.
Plug a compatible fiber module into the SFP port.
Compatible SFP+ modules are: QUESTION!
Connect to Management Port
The management port is designed for Out-of-Band management.
The SD-Switch can be managed via this port only by default.
The management Port IP address is 192.168.1.254/24
Connect a RJ45 to the management port and a client device.
Configure the client device with an IP address in the 192.168.1.0/24 range.
Open a web browser and enter the default IP address of the management port in the address
field of the web browser ( http:\\192.168.1.254) to access the web interface of the Peplink
Switch.
