Pepperl+Fuchs 6000 SERIES Manual

6500 Series Purge and Pressurization System
I/O Manual
65
User Interface Simulation
 Safe Pressure

Enclosure Power

Rapid Exchange

System Bypass

Alarm / Fault
LED Status Nonfiction
Start / Set
Enter / Set selected programming option
6000 Series
5500 Series
Setup

Purge Settings

Units

Input Settings

Output Settings

Passwords

Language

Bypass Control

Factory Restore
Exit
Return to main screen / exit parameter
Stats

Show Statistics

Show Alarm

Show Fault

Clear Statistics

Clear Fault
Information
Detailed information relating to the active
parameter / screen selected within the
program menu.
Access Simulate Actions
Feature
Arrow Keys

Cycle through menu options

Enter password

Cycle through enclosure statistics on
main operating screen
 K1 - Enclosure
Power on

K2 - Aux Contact on

P/SV - Safe
Enclosure Pressure /
Valve on

System Bypass

PT100 Fault
LED Status Nonfiction
Setup

Enter Program Tree
(hold 5 secs)
 Purge Program
 Purge Time
 Enclosure Pressure
Points (P1 - P4)
 Leakage /
Hysteresis
 Temperature
Settings (Digital
Valve or Aux
Contact)
 Bypass
 Units
 Enter / set selected
programming option
Information
Detailed information relating to the active
parameter / screen selected within the program
menu.
Arrow Keys

Cycle through menu options

Enter password

Cycle through enclosure statistics on
main operating screen
Arrow Keys

Exit parameter

Reset power (hold 5 secs.)
