5.2.2 DIP Switch Settings
The device is equipped with 8 DIP switches on the front.
DIP switch 1 is used for device testing by the manufacturer and must therefore always be in
the off position.
DIP switches 2 and 3 determine the baud rate of the RS-485 interface.
DIP switches 4 to 8 define the RS-485 address. A value assigned to each of the DIP switches.
The address is calculated from the sum of the values.
Danger!
Explosion hazard from sparking when using operating elements
Using operating elements in a potentially explosive atmosphere can cause sparks that can
ignite the surrounding atmosphere.
Only use operating elements (e. g., switch, slider, button, etc.) in the absence of a potentially
explosive atmosphere.
DIP switch 1 Meaning
Position Off Normal state
Table 5.1
DIP switch 2 3 Meaning
Position Off Off 9600 baud
Off On 19200 baud
On Off 38400 baud
On On 57600 baud
Table 5.2
DIP switch 4 5 6 7 8 Meaning
Position On Off Off Off Off Value 16
Off On Off Off Off Value 8
Off Off On Off Off Value 4
Off Off Off On Off Value 2
Off Off Off Off On Value 1
Example Off On On Off On Address=8+4+1=13
Table 5.3
Note!
Briefly disconnect the device from the power supply to apply the values set using
the DIP switches.
