6.1 Addressing operating mode
The addressing is divided into 3 individual procedures. The following table shows
the individual processes:
Navigating through addresses / selecting source address when several
slaves are connected
Press the button to select the AS-Interface slave to which you want to assign
a new address. If several AS-Interface slaves are connected to the addressing
device, press the button several times or press and hold the button and
scroll through the addresses using the and buttons.
Synonymous use of standard and A addresses
1. To assign an address to a connected slave with or without extended address-
ing, it is sufficient to specify a target address in the standard address area or
in address area A. For a slave without extended addressing, the addressing
device assigns the set address automatically in the standard address area.
For a slave with extended addressing, the addressing device assigns the set
address automatically as an A address.
2. To assign an address in address area B, you must specify target address area
B. See "Setting the target address" on page 17. If a slave without extended
addressing is connected, the addressing device shows a fault message.
Note!
When addressing AS-Interface slaves connected to the handheld, make sure that
the address 0 is not occupied. Otherwise, an error message may occur.
Procedure Addressing
Selecting the source
address
■ one AS-Interface slave connected: The address of
the connected AS-Interface slave is automatically
detected as the source address.
■ several AS-Interface slaves connected: The source
address must be manually selected, see "Navigating
through addresses / selecting source address when
several slaves are connected" on page 16.
Selection of target address See "Setting the target address" on page 17
When being addressed, if the target address is occupied
by a further connected AS-Interface slave, the
addressing device issues an error message.
Start addressing See "Starting addressing" on page 17
ADR ADR
Note!
When addressing a slave, the address area of the target address is automatically
adapted to the connected slave:
To Next Page
