Pepperl+Fuchs VBP-HH1-V3.0 User Manual

2013-06
8
VBP-HH1-V3.0*
Product Description
■ Extension of the ID-Codes of the AS-Interface slaves.
Specification 2.1 AS-Interface slaves (A/B slaves) have the hexadecimal
value A as the ID-Code and have 2 more identification codes (ID1 and ID2)
that describe the functionality of the slave. You have the option of
describing the ID1-Code.
The ID-Code for standard AS-Interface slaves differs from the ID-Code of
the A/B slaves. With standard AS-Interface slaves, no further identification
codes are included.
4.2 Use and application of the handheld
AS-Interface slaves are usually addressed with a handheld. As a rule, a number of
steps are necessary to address the slaves and in the future you will be able to
execute this procedure faster using the handheld:
■ Unique addressing of the AS-Interface slaves
■ Power supply to the AS-Interfa ce slaves via th e handheld
■ Functio n checks – even without programmable logic controller (PLC)
4.3 Delivery package
The delivery package contains:
Figure 4.1
1) =
VBP-HH1-V3.0-KIT-110V only
Note!
If you have changed the ID1-Code and want to automatically program the
address, check before the installation of the new AS-Interface slave that the ID1-
Code has been correctly stored in the AS-Interface slave.
VBP-HH1-V3.0
VBP-HH1-V3.0-110V
VBP-HH1-V3.0-KIT
VBP-HH1-V3.0-KIT-110V
■ Addressing device
■ Charger
■ Quick start guide
■ Add ressing device
■ Charger
■ Quick start guide
■ Case
■ Four programming cables:
VAZ-PK-1.5M-V1-G1,
V1S-G-1M-PUR
1)
,
V1-G-0.3M-PUR-V1-G
1)
and
VAZ-PK-FK-0.2M-V1-W
1)
