2013-06
18
VBP-HH1-V3.0*
Operation
Write ID1 Code
To write an ID1 Code to the active AS-Interface slave, proceed as follows:
1. Set the desired value for the ID1 Code with the and buttons.
The RDdisplay goes out when scrolling up and down.
2. Press the button to write the desired value permanently to the active AS-
Interface slave,.
WRappears in the operating mode display.
6.4 Read ID2 operating mode
As soon as you switch to the Read ID2 operating mode, the ID2 code of the active
AS-Interface slave is read in and is shown in the address and data display. It is not
possible to change this value.
Repeat reading
To repeat the reading of the code, press the button.
6.5 Read IO operating mode
As soon as you switch to the Read IO operating mode, the IO code of the active
AS-Interface slave is read in and is shown in the address and data display.
Repeat reading
To repeat the reading of the code, press the button.
6.6 Read Peripheral Fault operating mode
As soon as you switch to the Read Peripheral Fault operating mode, the address
and data display indicates if there is a peripheral fault on the AS-Interface slave. A
peripheral fault is present if the value 1 is displayed. The cause of the fault
depends on the AS-Interface slave being used.
Repeat reading
To repeat the reading of the code, press the button.
Note!
The value of the ID1 Code ranges from 0 to 15 for standard AS-Interface slaves
and from 0 to 7 for A/B slaves.
Note!
AS-Interface Specification 2.1
This function applies only to AS-Interface slaves that support Specification 2.1.
ADR
