Operation
The set output data value is temporarily stored in the handheld. The output data
value is shown on the display as long as you do not press the , or
buttons. If the displayed output data value deviates from the stored output data
after pressing the button, then:
1. press the button once. The set output data are shown and the RD goes
out.
2. Set the desired output data value if necessary using the and buttons
or
3. briefly press the button to temporarily save the set output data value and
transmit it once to the active AS-Interface slave.
The set data value is retained until:
■ You change the active address in the Addressing operating mode,
■ You replace the AS-Interface slaves which have the same address but
different ID, ID2, or IO codes.
■ The addressing device is automatically switched off or manually switched
off after a long period without use.
Reading data from the AS-Interface slave
To read the input data from the AS-Interface slave, briefly press the button. If
you press the button for at least 2 seconds, the input data from the AS-
Interface slave is cyclically read and the output data from the addressing device is
sent to the AS-Interface slave. This continues until you press any button on the
addressing device. The addressing devices does not switch itself off.
Complex communication protocols
The addressing device supports the following complex communication protocols:
■ AS-Interface slaves with the profile S-7.A.7 are detected as AS-Interface
slaves with extended addressing and 4 inputs and 4 outputs and are
correctly handled.
■ AS-Interface slaves with the Profile S-0.B and S-7.B are detected as AS-
Interface slaves and handled in accordance with AS-Interface at Work.
Tip
Checking output data
You can check the set output data by briefly pressing the or button. The
set output data are displayed. No data is transferred to the slave.
ADR
PRG
Note!
When input data are read from the AS-Interface slave, the output data and/or
parameter values are also automatically transmitted from the addressing device to
the AS-Interface slave. Check that these values do not endanger the trouble-free
operation of your plant.
