MULTIFLEX Girder Slab Formwork
Assembly Instructions for Standard Configuration
Content
Introduction
Overview, Main Components 1
Intended Use 2
Misapplications 2
General Safety Instructions 3
Safety Instructions System-Specific 4
Additional Product Information 4
Care and Maintenance Instructions 5
Assembly and Dismantling
A1 Storage and Transportation 6
A2 Components
Plywood Formlining 7
Formwork Girders 8
Slab Props, Formwork Support 11
Assembly Aids, Shuttering Aids 12
A3 Shuttering
Shuttering 14
Formwork Assembly 16
A4 Guardrails, Stopend Formwork
At the Slab Edge 17
On Casting Segments 17
A5 Striking 18
A6 Beams, Stopend Formwork
With Beam Formwork UZ 20
With Stopend Angle AW 21
A7 Example of Use 22
A8 Dimensioning of the Slab Formwork 24
Tables
Formlining 26
GT 24 as Slab Girder 28
VT 20 as Slab Girder 30
2 x GT 24 as Main Girder 32
2 x VT 20 as Main Girder 34
PEP Slab Props 36
MULTIPROP Slab Props 44
Beam Formwork UZ 46
Stopend Angle AW 47
Components
Components 48
Key
Safety Instructions
Note Tip PSAgA
Visual Check
Load-Bearing Point Safety helmet Safety goggles
Safety gloves Safety shoes
To Next Page
