Peri MULTIFLEX - MULTIFLEX Girder Load Tables; GT 24 as Slab Girder

28
0.10 0.12 0.14 0.16 0.18 0.20
4.4 4.8 5.3 5.8 6.3 6.8
0.75 0.625 0.50 0.75 0.625 0.50 0.75 0.625 0.50 0.75 0.625 0.50 0.75 0.625 0.50 0.75 0.625 0.50
0.30 0.60
3.99 4.24 4.57 3.79 4.03 4.34 3.62 3.85 4.14 3.48 3.70 3.98 3.36 3.57 3.84 3.25 3.45 3.72
10.9 11.6 12.5 11.6 12.3 13.2 12.2 12.9 13.9 12.8 13.5 14.6 13.3 14.2 15.3 13.9 14.8 15.9
0.45 0.90
3.99 4.24 4.57 3.79 4.03 4.34 3.62 3.85 4.14 3.48 3.70 3.98 3.36 3.57 3.84 3.25 3.45 3.72
16.4 17.4 18.8 17.3 18.4 19.8 18.2 19.4 20.9 19.1 20.3 21.9 20.0 21.3 22.9 20.9 22.2 23.9
0.45 1.20
3.99 4.24 4.57 3.79 4.03 4.34 3.62 3.85 4.14 3.48 3.70 3.82 3.36 3.52 3.52 3.25 3.27 3.27
21.9 23.3 25.1 23.1 24.6 26.4 24.3 25.8 27.8 25.5 27.1 28.0 26.7 28.0 28.0 27.8 28.0 28.0
0.45 1.50
3.99 4.09 4.09 3.67 3.67 3.67 3.34 3.34 3.34 3.05 3.05 3.05 2.82 2.82 2.82 2.61 2.61 2.61
27.4 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0
0.45 1.80
3.41 3.41 3.41 3.06 3.06 3.06 2.78 2.78 2.78 2.55 2.55 2.55 2.35 2.35 2.35 2.18 2.18 2.18
28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0
0.45 2.10
2.92 2.92 2.92 2.62 2.62 2.62 2.38 2.38 2.38 2.18 2.18 2.18 2.01 2.01 2.01 1.87 1.87 1.87
28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0
0.22 0.24 0.25 0.26 0.28 0.30
7.3 7.8 8.0 8.3 8.8 9.3
0.75 0.625 0.50 0.625 0.50 0.40 0.625 0.50 0.40 0.625 0.50 0.40 0.625 0.50 0.40 0.625 0.50 0.40
0.30 0.60
3.15 3.35 3.61 3.26 3.51 3.79 3.22 3.47 3.74 3.18 3.43 3.69 3.11 3.35 3.61 3.04 3.28 3.53
14.5 15.4 16.6 16.0 17.2 18.6 16.3 17.5 18.9 16.6 17.9 19.2 17.2 18.5 19.9 17.7 19.1 20.6
0.45 0.90
3.15 3.35 3.61 3.26 3.51 3.79 3.22 3.47 3.69 3.18 3.43 3.58 3.11 3.35 3.38 3.04 3.20 3.20
21.7 23.1 24.9 24.0 25.8 27.8 24.4 26.3 28.0 24.9 26.8 28.0 25.7 27.7 28.0 26.6 28.0 28.0
0.45 1.20
3.05 3.05 3.05 2.86 2.86 2.86 2.77 2.77 2.77 2.69 2.69 2.69 2.54 2.54 2.54 2.40 2.40 2.40
28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0
0.45 1.50
2.44 2.44 2.44 2.29 2.29 2.29 2.22 2.22 2.22 2.15 2.15 2.15 2.03 2.03 2.03 1.92 1.92 1.92
28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0
0.45 1.80
2.03 2.03 2.03 1.90 1.90 1.90 1.85 1.85 1.85 1.79 1.79 1.79 1.69 1.69 1.69 1.60 1.60 1.60
28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0
0.45 2.10
1.74 1.74 1.74 1.63 1.63 1.63 1.58 1.58 1.58 1.54 1.54 1.54 1.45 1.45 1.45 1.37 1.37 1.37
28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0 28.0
MULTIFLEX
GT 24 used as Slab Girder
Prop Spacing c [m]
Cantilever e [m]
Cantilever e [m]
Slab Thickness
d [m]
Load
q* [kN/m
2
]
Sec. Girder
Spacing a [m]
Prop Spacing c [m]
Slab Thickness
d [m]
Load
q* [kN/m
2
]
Sec. Girder
Spacing a [m]
